Brake Disc ADW194316 Blue Print
No specifications available yet
Back to category
Brake Disc 08.5709.10 Brembo
Product number: 0164531
Manufacturer number: 08.5709.10
EAN: 8020584570913
-
Free 30 days exchanges
-
Quality car parts
-
EU Delivery: 2-3 days
-
Ask our experts for advice
Customer service: +31 85 070 52 25
Ask your question at our product specialists.
Questions and answers.
Fit guarantee, show parts suitable for your vehicle.
Please your vehicle
-
Specifications
torque [Nm]: 11
Outer diameter [mm] 280 Brake Disc Type Solid Diameter [mm] 280 Number of Holes 4 Montage Front Brake pads Exclusive Surface Anti-rust coating Centering Diameter [mm] 68 Machining High-carbon Torque [Nm] 120 Guarantee 2 years Height [mm] 56 Brake disc thickness (mm) 13 Minimum thickness (mm) 11 Similar products of other manufacturers
Manufacturer Manufacturer number Price A.B.S. 16201 A.Z. Meisterteile AZMT-44-024-1461 ABE C3A014ABE AISIN T6F1496S AMBMI RDV-027 BELACO BDS1754 BOGAP A8211285 BORG & BECK BBD4971 BOSCH 0 986 478 131 BRAXIS AE0481 BREMBO 08.5709.10 (this product) BREMSI CD6518S Burig B010868 BÖLK BOL-BD8014 CAR HPD 736 CAR 142.736 CHAMPION 561688CH CIFAM 800-329 DACO 604741 DANAHER DR10146 DANBLOCK DB 521983 DELPHI BG2783 DENCKERMANN B130018 DIAMAX N08264 DON PCD12332 Dr!ve+ DP1010.11.0844 EUROBRAKE 5815204741 EUROBRAKE 5815314741 EUROREPAR 1618868280 FEBI BILSTEIN 08553 FEBI BILSTEIN 11203 FERODO DDF518C FERODO DDF518 FTE 9072843 FTE 9082694 GIRLING 6025973 HELLA 8DD 355 103-071 ICER 78BD8014-2 JPN 30H9130-JPN JURID 561688JC JURID 561688J KAWE 6287 00 LPR A1391P MAGNETI MARELLI 360406012500 MANDO MBC035718 MAPCO 15865 MASTER-SPORT 24011301791-SET-MS Manufacturer Manufacturer number Price MASTER-SPORT 24011301791-SET-MSP MAXGEAR 19-0782SPORT MAXGEAR 19-0782 MAXGEAR 19-0782MAX MAXTECH 871066 METELLI 23-0329 MEYLE 115 521 1024 MINTEX MDC812 MJA MB100259 MOTAQUIP LVBD566Z MOTRIO 8671000091 NATIONAL NBD505 NK 204741 NK 314741 OPTIMAL BS-2870C PAGID 53922NC PAGID 53922N PILENGA 5361 ProfiPower 3B1230 QUARO QD8784 R BRAKE 78RBD28014 RAICAM RD00868 RAP BRAKES R-D0800 REMSA 6287.00 RIDEX 82B0383 ROADHOUSE 6287.00 ROTINGER RT 1192-GL T6 ROTINGER RT 1192-GL T3 ROTINGER RT 1192-GL T5 ROTINGER RT 1192-GL ROTINGER RT 1192 ROTINGER RT 1192-GL T9 SAMKO A1391P SASIC 9004492J SRLine S71-0231 STARK SKBD-0020388 SWAG 32 90 8553 TEXTAR 92060400 TOMEX Brakes TX 71-03 TRISCAN 8120 29117C TRUSTING DF136 TRW DF2597 VAICO V10-40020 VALEO 673470 VALEO 186269 WOKING D6287.00 ZIMMERMANN 100.1221.20 -
Applicability
AUDI 80 B4 80 B4 Avant (8C5) | 09.1991-01.1996 1.9 TD - 1896ccm, 75pk, 55kw - AAZ 80 B4 Avant (8C5) | 09.1991-01.1996 1.9 TDI - 1896ccm, 90pk, 66kw - 1Z 80 B4 Avant (8C5) | 09.1991-01.1996 2.0 - 1984ccm, 90pk, 66kw - ABT 80 B4 Saloon (8C2) | 09.1991-12.1994 1.6 - 1595ccm, 71pk, 52kw - ABM 80 B4 Saloon (8C2) | 09.1991-12.1994 1.9 TD - 1896ccm, 75pk, 55kw - AAZ 80 B4 Saloon (8C2) | 09.1991-12.1994 1.9 TDI - 1896ccm, 90pk, 66kw - 1Z 80 B4 Saloon (8C2) | 09.1991-12.1994 2.0 - 1984ccm, 90pk, 66kw - ABT -
Original part numbers
8A0615301 AUDI 8A0615301D AUDI -
Manufacturer
Brembo is the undisputed leader in the production and development of brake parts for the automotive industry. Brembo stands for the best braking performance for your car. Brembo has built up enormous expertise to be able to develop and produce a wide variety of products. From brake pads and discs for over 96% of all passenger cars in Europe, America and Asia, to extreme braking systems used in Supercars and Formula 1.
The technical innovation and durability of Brembo brake pads and brake discs is guaranteed because all important processes such as design, production and testing are under one roof. As a result, Brembo brake pads and brake discs always deliver the best performance, time after time.
Brembo sport brake discs are cast, finished and tested by Brembo itself, so that exceptional quality can be guaranteed. Every newly produced Brembo brake disc thus has the same exceptional quality as the previous one.
Brembo brake parts distinguish themselves on the following points:
• Coverage of over 96% of the worldwide passenger car fleet
• Top quality
• Sportsmanship
• Better braking performance than other manufacturers
• Number 1 braking system used in sports cars and Formula 1
We currently have the following Brembo products in our range:
• Brake pads
• Brake discs
• Brake Shoe Set
• Wear Indicators
• Brake drums
• Calipers
• Brake hoses
• Wheel brake cylinders
• Master cylinders
• Penetrating Oil & Lubricants
• Brake power distributors
Is sportsmanship important to you? Then order Brembo brake parts!
-
