Camshaft Adjuster IPD
No specifications available yet
Back to category
Piston
Product number: 1184405
Manufacturer number: 030 41 00
EAN: 4009026524879
-
Free 30 days exchanges
-
Quality car parts
-
EU Delivery: 2-3 days
-
Ask our experts for advice
Customer service: +31 85 070 52 25
Ask your question at our product specialists.
Questions and answers.
Fit guarantee, show parts suitable for your vehicle.
Please your vehicle
-
Specifications
Fitting Position To cylinder 3 To cylinder 4 For cylinder 3 - 4 Supplementary Article/Info 2 With piston ring carrier Without cooling channel Surface Coated Machined With recess for oil sprayer Production Number 79 L 46 Packaging length [cm] 9,5 Packaging width [cm] 9,50 Packaging height [cm] 12,80 Recess Diameter [mm] 37,9 Recess Depth 1 [mm] 17,65 Guarantee 2 years Bolt length [mm] 66,0 Component Number 1. R 1.75 Cr P 2.M2.0 IFU Cr P 3. DSF 3.0 Cr Length [mm] 71,8 Standard Size [STD] Compression Height [mm] 45,8 Valve pocket depth 1 [mm] 1,1 Top land height [mm] 9,1 Net Weight [g] 800 Piston clearance [mm] 0,07 Cylinder bore [mm] 79,51 Bolt diameter [mm] 26,0 Similar products of other manufacturers
-
Original part numbers
028107065AB AUDI 028107101AK AUDI 038107065L AUDI 028107065AC AUDI 028107065BD AUDI 028107065J AUDI 028107065CB AUDI 028107065CA AUDI 038107065DD AUDI 028107065AM AUDI 028107065AK AUDI 038107065AB001 AUDI 038107065AB003 AUDI 038107065J AUDI 028107065AB CUPRA 028107101AK CUPRA 038107065L CUPRA 028107065AC CUPRA 028107065BD CUPRA 028107065J CUPRA 028107065CB CUPRA 028107065CA CUPRA 038107065DD CUPRA 028107065AM CUPRA 028107065AK CUPRA 038107065AB001 CUPRA 038107065AB003 CUPRA 038107065J CUPRA 028 107 065 B D VW 038 107 065 AB001 VW 038 107 065 J VW 028 107 065 J VW 038 107 065 L VW 028 107 065 A C VW 038 107 065 AB003 VW 028 107 101 A K VW 028 107 065 A M VW 028 107 065 C B VW 038 107 065 D D VW 028 107 065 C A VW 028 107 065 A K VW 028 107 065 A B VW -
Manufacturer
Mahle/ Knecht filters specializes in everything that has to do with the internal combustion engine and its immediate environment
More than 140 renowned motorcycle and vehicle manufacturers now equip their engines with MAHLE engine parts and filters as standard.
At Winparts we offer the following products from Mahle, among others: -
